Rotary 220V Automatic steam Press Cloth Machine , Steam Cloth Iron
Press Machine steam heating system blazer suit
I. factory introd
Agent & factory Customers are all in China, in Southeast Asia,
Europe, America, Africa and other countries
Our cor has passed is090001-2015 quality system certification high
level.
There are 5 main departments, such as technology development
department, product design department, product sales department,
accounting department and production management department. The
main products include: 1 - suit ironing machine 2 - shirt ironing
machine 3 - trousers ironing machine.
This steam press is used for shaped-fixed and ironing processing
for suits, the trousers' legs and rousers which made of woool,
synthetic fibric, it is easy in maintance and adaptable to medium
and small-size garment manufactures.
The machine can be operated manually or automatic that the air
operated automatic steam press.
II. Automatic suit jacket press machine (Front)
| Model | CYHJ-14055R |
| Control | Automatic touch-screen PLC color 7" screen |
| Total pressure | 900kg UP |
| Steam | 0.4-0.6MPa (30kg/h) 1/2” |
| Compress air | 0.4-0.6MPa (35L/min) 8mm |
| Electric power | 220V/1ph/50HZ |
| Vacuum | 1.5kw extra vacuum pump 2” OR build-in |
| Drained water | 1/2” |
| Dimension | 1700x1700x1750mm |
| Net weight | 850kg |
III. Feature
workiing position: one load/unload, one press
increase efficience and production
Vertically press: full surface move down at same time to make
pressure equally
(All buck surface press at same time)
Aluninium material buck is suitable for garment
(customizable)
electric heting system supplis with high temperature
Automatic Touch-screen PLC
3 level safety protection device
input and output signal
(easy to check faulty)
Bottom buck has vacuum
Famous pneumatic parts
IV. Full final suit press machine list
| NO. | Model | Description of machine | Dimension: L x W x H mm |
| 1 | CYHJ-107.108 | Left right front press | 1700x1700x1750 |
| 2 | CYHJ-122.123 | Left ight back press | 1700x1700x1750 |
| 3 | CXAJ-122 | Left back press | 1200x1200x1650 |
| 4 | CXAJ-123 | Right back press | 1200x1200x1650 |
| 5 | CYHJ-126 | Double lapel | 1700x1700x1750 |
| 6 | CXEJ-116.117 | Double shoulder | 1000x1000x2150 |
| 7 | CXGJ-547 | Collar master | 1100x1100x2150 |
| 8 | CZBJ-104 | Sleeve front | 900x1200x1300 |
| 9 | CZBJ-105 | Sleeve elbow | 900x1200x1300 |
| 10 | CZBJ-114 | Sleeve arm-hole | 900x1200x1300 |
| 11 | CABJ-114-14 | Sleeve blocking | 900x1200x1300
|
Shanghai Jiejia Garment Machinery Co., Ltd. was registered in 1998.
Over 20 years we developed 5 series of main product:
- Fabric shrink / inspect / fuse machinery
- Suits pressing machinery
- Pant machinery
- Shirt machinery
- Jeans machinery
- Knitting machinery
Any customer could find his satisfied machinery and acceptable
price for economical class or high class.
Jiejia could supply with full solution for all kinds of garment
ironing purpose like: suits, pant, shirt, T-shirt, sweater, coat
and so on.
V. Q&A
1.How could I get more information?
please contact with: barclay_yang@163.com sales01@jiejia-bygood.com
2. Do you have another type of machine ?
Yes. we have 3 different levels of machine for your reference
3. Do you have any customer factory to see?
Yes. please contect with us to find close one for you.
4. Do you have machine video?
Yes. please contact with us.
5. Are you factory?
Yes. We have manufactured for over 20 years.
=========================================
Auto press machine for suit jacket uniform interlining steam
ironing equipment with vacuum suction
